RG-AP840-L

RG-AP840-L

Dual-Radio Wi-Fi 6 Indoor Wireless Access Point

• 1 x 100/ 1000/2500/5000Base-T Ethernet port 1 x 5GE combo port, 1 x 10/100/1000Base-T Ethernet port
• Wi-Fi 6E (IEEE 802.11a/b/g/n/ac/ax)Dual-radio: 2.4 GHz (2×2), 5 GHz (4×4) up to 6 spatial streams
• Combined peak data rate: 2.4 GHz + 5 GHz, 5.378 Gbps
• Built-in omnidirectional antennas
• Support Wall/Ceiling mounting
• Support 150 Concurrent Users
• Support Cloud Remote Management

Description

Specification:

Wireless Protocol802.11a/b/g/n/ac/ax
Radio DesignDual-radio: 2.4 GHz (2×2), 5 GHz (4×4)
up to 6 spatial streams
Data RateCombined peak data rate: 2.4 GHz + 5 GHz, 5.378 Gbps
Antenna TypeBuilt-in omnidirectional antennas
Fixed Service Port1 x 100/1000/2.5G/5GBASE-T port
1 x 5GE SFP/RJ45 combo port
1 x 10/100/1000BASE-T port
BluetoothBluetooth 5.1
Input Power Supply54 V DC/1.1 A power supply
PoE/PoE+/PoE++ (802.3af/at/bt)
Max. Power Consumption40 W
External Power SupplyYes
Operating Temperature –10°C to +50°C (14°F to +122°F)
Dimension230 mm x 230 mm x 51 mm (9.06 in. x 9.06 in. x 2.01 in.)
MountingWall/Ceiling-mount



DATASHEET
