AR725H SOYAL TOUCH PANEL READER

AR725H SOYAL TOUCH PANEL READER

Touch panel reader (EM 125KHZ / MIFARE 13.56MHZ)

• Reading range: 10 – 15cm
• Standalone – 3000 users, 1500 transaction memory.
• 11 time zone.
• Able to connect to AR716EV

Description

AR725H is a card access reader typically installed at door, pedestrian gate and barrier gate to restrict unauthorized access. It reads EM proximity card. It supports an RS485 connection, 3000 users and 1500 event memory. It has a built-in touch panel keypad.

Built-in tamper-proof function to alert you on software if someone removed or vandalize the reader. The alarm function will alert you with an external buzzer if the door is not fully closed or someone opens the door by force without flashing a valid card. AR725H uses a patented anti-vibration relay design that prevents intruders to open your door by just knocking hard onto the reader.

DATASHEET
